Boats, yachts, lorries, wherever 24 volts are used and you do not want to do without the convenience of a pressurised water system, but also suitable for the city water network, for the home and garden for operation with 24 volts from the solar system, wind generator, battery or power supply unit.
The boiler is compact and can be easily installed or integrated into existing water systems. The tank is fully insulated (foamed) to reduce heat and energy loss, the water remains warm for 40 hours after the appliance is switched off. (Like a thermos flask)
When fully heated, two to three times the amount of hot water can be drawn off by adding cold water, depending on the input temperature.
After switching on the appliance, hot water can be drawn off after 40 minutes. The ceramic-coated boiler is constructed vertically, the big advantage: the hot water collects at the top due to the greater height difference and does not mix with the incoming cold water, hot water can be drawn off down to the last drop.
How it works:
After pressing the temperature control on the front, it lights up (appliance is in operation) until the set temperature is reached via the temperature control, then the indicator light goes out and the appliance switches off although the temperature control is switched on (the set temperature is reached). As long as the temperature control remains switched on, the appliance will maintain the set temperature and the heating element is only switched on briefly. This can be seen from the indicator light which then lights up again for a short time. The power consumption is then approximately 1.5 A/h at the set 60° (ECO position)/depending on the ambient temperature.
Safety:
-The temperature switch and the associated probe switch off the appliance at a maximum temperature of 75°C. If this system fails, a safety switch jumps out. If this system fails, a second separate system kicks in, a temperature fuse and the associated temperature probe switch the entire appliance off at 85°C. (the second system works purely mechanically). (the second system works purely mechanically and requires no power).
Optionally available: Remote switch with temperature display and 8 metre cable
Technical data:
-Pressure-resistant up to 6 bar
-Volume 30 litres
-Voltage 24 volts (voltage range 20.0 volts - 29.2 volts)
-Hot water can be drawn off after just 40 minutes.
-Power 400 Watt 16a
-Temperature range 10-75C° adjustable
-Easy tank emptying
-2 point fixing
-Dimensions HxWxD 568 x 387 x 410 mm.
-Heating time approx. 4 hours (depending on water inlet temperature and voltage. (max 29.2 volts) Hot water can be drawn off after just 40 minutes.
